?MegaPhase微波射頻定向就業解耦器
發布了(le)準確時間：2023-03-28 16:45:00 預覽：1429
MegaPhaserfrf射頻定向招生招生合體用電線路用品備各個面合體用電線路用電線路值和頻段厚度以要求更好制定運用和制定消費需求。rfrf射頻定向招生招生合體用電線路器制定用來最合理的實驗性室內環境，夠要求軍民融合用Lk線和空間機系統的要從嚴工作。MegaPhase微波射頻定項耦合電路系統電路系統器也能在之多封裝形式和進行防水連接器系列作品中完工耦合電路系統電路系統電路系統值、缺省性和插進耗損率的嚴歷公差。
窄帶縱向藕合器：
倍(bei)頻(pin)程(cheng)和(he)多倍(bei)頻(pin)程(cheng)的(de)頻(pin)率段至12GHz
6、10、20和30dB解(jie)耦電(dian)路(lu)板
具備(bei)條件(jian)N型、SMA型和2.92mm無線電源連接器
大瓦數、低插入表(biao)格(ge)不足(zu)
設計方(fang)案要求MIL-DTL-15370
適用于的區域篩分
窄帶專向合體器：
光纖寬帶至(zhi)26.5GHz
10、16、20dB藕合電(dian)路原理
25W工作(zuo)功率解決方法(fa)
SMA和(he)2.92mm連(lian)結器可用(yong)于
設(she)計充(chong)分考慮(lv)MIL-DTL-15370條(tiao)件的標準(zhun)
可對其進行選取
網絡帶寬定向(xiang)分配交叉耦合(he)器(qi)：
多(duo)倍頻程(cheng)帶至(zhi)18GHz
T6、10、20和30dB合(he)體電源(yuan)線路(lu)
50W馬力解決方法
兼具N型、SMA型和2.92mm聯(lian)系器
來(lai)設計擁有MIL-DTL-15370
適用性的場景淘汰
MegaPhase毫米(mi)左右波元元器(qi)確立于(yu)(yu)1998年(nian)，是法國知名的(de)的(de)紅外光(guang)拖鏈電(dian)纜供應(ying)信(xin)息商。MegaPhase裝修公(gong)司制定和研發高可(ke)靠的(de)性(xing)頻射同基準面(mian)纜、進(jin)行電(dian)源連接(jie)器(qi)軟件，MegaPhase毫米(mi)左右波光(guang)纜物品(pin)具有廣泛性(xing)應(ying)用軟件提供服務(wu)于(yu)(yu)微波光(guang)纖(xian)通(tong)信(xin)網(wang)(wang)射頻于(yu)(yu)微波光(guang)纖(xian)通(tong)信(xin)網(wang)(wang)射頻于(yu)(yu)光(guang)電(dian)系(xi)統，更是是試驗、防務(wu)光(guang)電(dian)子、衛(wei)星影像(xiang)光(guang)纖(xian)通(tong)信(xin)網(wang)(wang)、光(guang)纖(xian)寬帶數(shu)據報告光(guang)纖(xian)通(tong)信(xin)網(wang)(wang)等。MegaPhase護膚品(pin)線聲音頻率(lv)相當(dang)于(yu)(yu)到DC-110GHz.
東莞市立維創展(zhan)(zhan)創新科(ke)技品牌(pai)授權代(dai)里銷(xiao)售額MegaPhase類產品，最主要出示(shi)MegaPhase產品的穩(wen)相(xiang)高壓低(di)壓電(dian)纜(lan)(lan)和高壓低(di)壓電(dian)纜(lan)(lan)零部件，并展(zhan)(zhan)示(shi)售服(fu)扶持服(fu)務(wu)培訓，歡(huan)迎(ying)語網絡(luo)咨詢。
內容了解MegaPhase微波電纜請點擊：//anchor-appliance.cn/brand/40.html
Narrow Band Dual Direction Couplers
MegaPhase Model No. | Type | Frequency Range (GHz) | Connectors | Coupling (dB, Nom.) | Frequency Sensitivity (dB, Max.) | Directivity (dB, Min.) | Insertion Loss (dB, Max) | Main Line VSWR | Coupled Line VSWR | Size |
DDC-40N-.17G | Dual 40 dB | .1 to .25 | N-F | 40 | 1 | 20 | 0.55 | 1.25 | 1.35 | 5.00 x 2.00 x 1.25 750 745 740 |
DDC-40NS-.17G | Dual 40 dB | N/SMA-F |
DDC-40NB-.17G | Dual 40 dB | N/BNC-F |
Wide Band Directional Couplers
MegaPhase Model No. | Type | Frequency Range (GHz) | Connectors | Coupling (dB, Nom.) | Frequency Sensitivity (dB, Max.) | Directivity (dB, Min.) | Insertion Loss (dB, Max) | Main Line VSWR | Coupled Line VSWR | Size |
DC27-10S-4G | 10 dB | 0.3 – 8.0 | SMA -F | 10, 20 | 1.2 | 15 | 1 | 1.5 | 1.5 | 6.00 x .73 x .50 |
DC27-20S-4G | 20 dB |
DC36-10S-9.2G | 10 dB | 0.5 – 18.5 | SMA -F | 10, 20 | 1.2 | 12 | 1.6 | 1.8 | 1.8 | 4.40 x .73 x .50 |
DC36-20S-9.2G | 20 dB |
DC9-10S -10G | 10 dB | 2.0-18.0 | SMA -F | 6, 10, 15 20, 30 dB | 1.2 | 12 10 (30 dB) | 1 | 1.8 | 1.8 | 2.25 x .73 x .50 |
DC9-15S-10G | 15 dB |
DC9-20S-10G | 20 dB |
DC9-30S-10G | 30 dB |
Narrow Band Directional Couplers
MegaPhase Model No. | Type | Frequency Range (GHz) | Connectors | Coupling (dB, Nom.) | Frequency Sensitivity (dB, Max.) | Directivity (dB, Min.) | Insertion Loss (dB, Max) | Main Line VSWR | Coupled Line VSWR | Size |
|
DC3-3N-.32 | 3 dB | .13-.520 | NF (C-5352-dB will be dual directional) | 3 to 40* (40 dB is 30 w/ internal pad) | 1 to 2 | 18 (3-7 dB) 20 (10+ dB) | 0.3 dB above theoretical coupling loss | 1.3 | 1.3 | 5.80 x 2.00 x 1.00 |
|
DC3-4N-.32 | 4 dB |
|
DC3-5N-.32 | 5 dB |
|
DC3-6N-.32 | 6 dB |
|
DC3-7N-.32 | 7 dB |
|
DC3-10N-.32 | 10 dB |
|
DC3-15N-.32 | 15 dB |
|
DC3-20N-.32 | 20 dB |
|
DC3-30N-.32 | 30 dB |
|
DC7-5N-1.5G | 5 dB | .38-2.7 | N-F | 5 to 30 dB | 1 | 20 | 0.7 | 1.35 | 1.35 | 6.46 x 1.21 x .72 343 312 283 |
|
DC7-6N-1.5G | 6 dB |
|
DC7-7N-1.5G | 7 dB |
|
DC7-10N-1.5G | 10 dB |
|
DC7-15N-1.5G | 15 dB |
|
DC7-20N-1.5G | 20 dB |
|
DC7-30N-1.5G | 30 dB |
|
DC2-XS-.75G* | 6, 10, 15, 20, 30 dB | 0.5 – 1.0 | SMA -F | 6, 10, 15, 20, 30 Db * | 1 | 20 dB (up to 4GHz) | 0.6 | 1.3 (up to 4GHz) | 1.3 (up to 4GHz) | 4.40 x .73 x .50 |
DC4-XS-1.25G* | 0.5 – 2.0 | 4.40 x .73 x .50 |
DC4-XS-1.7G* | 0.7 – 2.7 | 4.40 x .73 x .50 |
DC2-XS-1.5G* | 1.0 – 2.0 | 15 dB (up to 12GHz) | 1.5 (up to 12GHz) | 1.5 (up to 12GHz) | 3.50 x .73 x .50 |
DC4-XS-2.5G* | 1.0 – 4.0 | 3.50 x .73 x .50 |
DC2-XS-3G* | 2.0 – 4.0 | 2.25 x .73 x .50 |
DC2-XS-3.9G* | 2.6 – 5.2 | 12 dB (up to 18GHz) | 1.7 (up to 18GHz) | 1.7 (up to 18GHz) | 2.25 x .73 x .50 |
DC2-XS-6G* | 4.0 – 8.0 | 1.10 x .65 x .50 |
DC2-XS-9.5G* | 7.0 – 12.4 | 1.10 x .65 x .50 |
DC2-XS-15G* | 12.0– 18.0 | 1.10 x .65 x .50 |
